| Code | Diameter | Width |
| 13619-1 | 13″-16″ | 5″ – 130 mm |
| 13620 | 13″-16″ | 165 mm |
| 13620-3 | 14″-17″ | 6″ – 150 mm |
| 13622 | 14″-17″ | 180 mm |
| 13623 | 14″-17″ | 170 mm |
| 13624 | 14″-17″ | 180 mm |
| 13625 | 14″-17″ | 7-1/2″ – 190 mm |
| 13626 | 14″-17″ | 210 mm |
| 13627 | 14″-17″ | 9 1/4″ – 235 mm |
| 13627-5 | 14″-17″ | 9” – 230 mm |
| 13650 | 17″-20″ | 7-1/2” – 190 mm |
| 13652 | 17″-20″ | 6 1/2″ – 165 mm |
| 13653 | 17″-20″ | 9 3/4″ – 250 mm |
| 13654 | 17″-20″ | 11 3/4″ – 300 mm |
| 13655 | 17″-20″ | 6 3/4″ – 170 mm |
| 13655-2 | 17″-20″ | 13-1/4″ – 337 mm |
| 13656 | 17″-20″ | 8 1/4″ – 210 mm |
| 13657 | 17″-20″ | 13 1/2″ – 340 mm |
| 13657-6 | 17″-20″ | 370 mm |
| 13658 | 17″-20″ | 7-5/8″ – 195 mm |
| 13659 | 17″-20″ | 9″ – 230 mm |
| 13660 | 20″-22.5″ | 7 1/2″ – 190 mm |
| 13661 | 20″-22.5″ | 8 1/4″ – 210 mm |
| 13662 | 20″-22.5″ | 9″ – 230 mm |
| 13663 | 20″-22.5″ | 11 3/4″ – 300 mm |
| 13664 | 20″-22.5″ | 305 mm |
| 13665 | 20″-22.5″ | 325 mm |
| 13665-0 | 20″-22.5″ | 337 mm |
| 13666 | 22″-24.5″ | 8.25″ – 210 mm |
| 13667 | 22″-24.5″ | 9″ – 230 mm |
| 13668-1 | 22″-24.5″ | 11 3/4″ – 300 mm |
| 13669 | 22″-24.5″ | 14.5″ – 368 mm |
Expanding chuck
rims
rims detail
Mandrini a espansione
Fasce per mandrini National (Bandag), CRS, Orbitread, SCV, SIO, Matteuzzi e ABM.
Su richiesta sono disponibili altre misure.
